mqtt2otel

mqtt2otel is a powerful yet lightweight bridge between the MQTT messaging protocol, commonly used in the IoT (Internet of Things) context, and OpenTelemetry (Otel) protocol, which is typically used for professional application and infrastructure monitoring. The tool can subscribe to MQTT broker topics, process and enrich messages with additional information, and then generate Otel metrics or logs for further analysis using standard tools.

Best of both worlds#
Combine the power of low energy, light weight IOT communication used at millions of devices worldwide with the de facto industry standard of professional telemetry.
Enrich your data#
You can add additional data to your telemetry signals, name them, add descriptions, locations, manufactorers, capabilities or others.
Create dashboards with ease#
Open telemetry is the de facto standard for telemetry data and is supported by all major dashboard tools.

Why mqtt2otel?#

IoT systems often rely on MQTT for efficient communication, while modern applications use OpenTelemetry for monitoring and observability. mqtt2otel bridges this gap, enabling you to bring IoT data into your existing observability stack without custom integrations.

Use cases#

You may ask yourself, why should you send your mqtt payloads via mqtt2otel, instead of providing them to a dashboard tool directly. There are several reasons to do so:

Your dashboard tool may not support mqtt directly
You want to enrich data with attributes and further process the data, but your dashboard tool does not support that, or only supports that behind a paywall.

More complex use cases involve:

Data distribution#

---
config:
  flowchart:
    curve: stepBefore
---

flowchart LR
  mqttBroker[mqtt broker]
  subgraph mqtt2otel
    mqtt2otelmetric[metric<br/>attributes:<br/> device = 'sensor A'<br/>temp = 42°C]
    mqtt2otellog[log<br/>attributes:<br/> device = 'sensor A'<br/>timestamp = 10:23:15<br/>loglevel = Info<br/> message = 'operation completed']
  end
  otelCollector[otelCollector]
  metricsDashboard[metrics dashboard]
  logDashboard[log dashboard]

  mqttBroker -->|temp: 107.6°F| mqtt2otelmetric
  mqttBroker -->|10:23:15 Info operation completed| mqtt2otellog
  mqtt2otel -->|logs| logDashboard
  mqtt2otel -->|metrics| metricsDashboard
  mqtt2otel -->|metrics and logs| otelCollector

mqtt2otel is able to parse payloads and enrich them with attributes. It can process the data (e.g. convert to different units) and then distribute it to different otel endpoints that are optimized for different use cases.

Integrate into existing otel infrastructure#

---
config:
  flowchart:
    curve: stepAfter
---

flowchart LR
  mqtt2otel[mqtt2otel<br/>attributes:<br/> device = 'sensor A']
  applicationA[Application A<br/>attributes:<br/> application = 'A']
  applicationB[Application B<br/>attributes:<br/> application = 'B']
  otelCollector[otelCollector<br/>add attributes:<br/> location = 'factory A'<br/>...]
  mqtt2otel --> otelCollector
  applicationA --> otelCollector
  applicationB --> otelCollector
  otelCollector --> Dashboard

mqtt2otel integrates well into existing open telemetry infrastructure. In the presented example this is used to aggregate data from different otel sources and enrich it with further attributes, before sending it to a dashboaard tool.

Manage load#

---
config:
  flowchart:
    curve: stepBefore
---
flowchart LR
  subgraph internal network
    mqttBroker[mqtt broker]
    mqtt2otel
    otelCollector[otel collector]
  end
  subgraph external network
    otelCollectorTarget[dashboard]
  end

  mqttBroker --> mqtt2otel
  mqtt2otel -->|option A| otelCollectorTarget
  mqtt2otel --> otelCollector
  otelCollector -->|option B| otelCollectorTarget

mqtt2otel can be used to aggregate and batch data before it is send out to the internet to reduce network traffic [option A]. Alternatively it can use an existing otel collector infrastructure to do this [option B]. mqtt2otel can communicate asynchronously and synchronously giving additional options on how the load on the target node can be managed. This can significantly reduce pressure on the dashboard tool.

Background#

To learn more about the underlying technologies, check out the following resources:

Architecture#

mqtt2otel does not include an embedded MQTT broker or OpenTelemetry Collector. These components must be provided externally (this may change in future versions).

A typical setup looks like this:

flowchart LR
    IoT1(IoT device) -->|Publish| broker(Mqtt broker)
    IoT2(IoT device) -->|Publish| broker
    IoT3(IoT device) -->|Publish| broker
    mqtt2otel(mqtt2otel server) --> |Subscribe| broker
    broker --> |Send| mqtt2otel(mqtt2otel server)
    mqtt2otel -->|send| otel(Open telemetry endpoint<br/>e.g. an otel collector)
    otel -->|retrieve| mqtt2otel
    otel -->|send| dashboard(Dashboard tool)
    dashboard-->|retrieve| otel

Installation#

Installation instructions can be found in the documentation.

Documentation#

Please refer to the official documentation for further info.

Source code#

mqtt2otel is open source. The source code is available on GitHub.

Feedback#

If you would like to report an issue or propose an enhancement, you can do this on GitHub.

If you would like to join or start a discussion, or ask a question then welcome to our discussions page.
